Baldor IDM4111T
* Actual Product May Differ From Image
IDM4111T
Part Number: IDM4111T
Model/Spec Number: 781568144589
Manufacturer: Baldor
HP: 25
RPM: 1180
Frame:Iron
Frame Size:324T
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
TENV, TEFC, and TEBC 1000:1 Constant Torque, Provisions for encoder mounting , 3 Thermostats, Standard NEMA frame sizes
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$11,830.90 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Centrifugal Pumps, Fans, Extruders, Conveyors, Cranes, Hoists, Winders, Web processing, Process Control, Test Stands | ||||
| Enclosure: | TEBC | Frame Size: | 324T | Agency Approvals: | CSA;UR |
| Frame Material: | Iron | Poles: | 6 | Insulation Class: | H |
| Shaft Rotation: | Reversible | Base: | Rigid | Horsepower: | 25 Hp |
| Synchronous RPM: | 1200 | Speed RPM: | 1180 | Max Speed: | 3900 RPM |
| Base Speed: | 1200 RPM | Voltage: | 230/460V | Full Load Amps: | 63/32 |
| Service Factor: | 1.00 | Motor Weight: | 557.0 lbs | Duty Cycle: | Continuous |
| Overall Length: | 36.92 in | Frequency: | 60 Hz | Phase: | Three Phase |
| Efficiency: | 93 % | XP Temp Code: | Without | End Plate: | STANDARD |
| Bearing DE: | 6312 | Bearing ODE: | 6311 | Ambient Temp: | 40 °C |
| Shaft Diameter: | 2.1250 in | Inverter Duty: | Inverter Duty | Shaft Grounding: | No Shaft Grounding |
| IP Rating: | NONE | Standard: | NEMA | List: | 15440.00 |
