Baldor LPL75
* Actual Product May Differ From Image
LPL75
Part Number: LPL75
Model/Spec Number: 781568127872
Manufacturer: Baldor
HP: 3/4
RPM: 3600
Frame:Steel
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Low noise vibration dampening base, Dynamically balanced rotor to increase bearing life, Superior switch design provides optimized torque profiles, Robust heavy gauge steel design
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$994.66 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via UPS
Documents
Product Specifications
| Applications: | Fans, Air handling, Conveyors, Pumps, Material Handling, Machine Tools | ||||
| Enclosure: | TENV | Agency Approvals: | UR | Frame Material: | Steel |
| Poles: | 2 | Insulation Class: | B | Shaft Rotation: | Fixed Opposite Standard |
| Base: | Rigid | Horsepower: | 3/4 Hp | Synchronous RPM: | 3600 |
| Speed RPM: | 3600 | Voltage: | 115/230V | Full Load Amps: | 4.8/2.4 |
| Service Factor: | 1.00 | Motor Weight: | 48.0 lbs | Duty Cycle: | Continuous |
| Overall Length: | 14.37 in | Frequency: | 60 Hz | Phase: | Single Phase |
| Ambient Temp: | 40 °C | Shaft Diameter: | 0.6250 in | IP Rating: | NONE |
| Standard: | Other | List: | 1193.00 | ||
