Baldor VFSSP5M3546T-E-G
* Actual Product May Differ From Image
VFSSP5M3546T-E-G
Part Number: VFSSP5M3546T-E-G
Model/Spec Number: 781568598580
Manufacturer: Baldor
HP: 1
RPM: 1800
Frame:Stainless Steel
Frame Size:145TC
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
300 series stainless steel, Individually welded feet for ease of cleaning, Smooth heads on external drains & hardware, Welded and polished conduit box, Laser marked nameplate, Internal & External shaft sealing, 3 Year Warranty
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$2,961.92 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via UPS
Documents
Product Specifications
| Applications: | Caustic environment, Food Processing, High pressure washdown, Outdoors, Pumps, Wastewater, Sanitary washdown | ||||
| Enclosure: | TENV | Frame Size: | 145TC | Frame Material: | Stainless Steel |
| Poles: | 4 | Insulation Class: | H | Shaft Rotation: | Reversible |
| Base: | No Mounting | Horsepower: | 1 Hp | Speed RPM: | 1800 |
| Max Speed: | 4000 RPM | Base Speed: | 1800 RPM | Voltage: | 230/460V |
| Full Load Amps: | 2.4/1.2 | Service Factor: | 1.15 | Motor Weight: | 44.0 lbs |
| Duty Cycle: | Continuous | Overall Length: | 12.86 in | Phase: | Three Phase |
| Efficiency: | 88.5 % | XP Temp Code: | Without | Bearing DE: | 6205 |
| Bearing ODE: | 6205 | Ambient Temp: | 40 °C | Inverter Duty: | 03 |
| Shaft Grounding: | Shaft Grounding | IP Rating: | NONE | Standard: | NEMA |
| List: | 3714.00 | ||||
