Baldor CSPM4107TS
* Actual Product May Differ From Image
CSPM4107TS
Part Number: CSPM4107TS
Model/Spec Number: 781568599747
Manufacturer: Baldor
HP: 25
RPM: 3545
Frame:Iron
Frame Size:284TSC
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Suitable for inverter use per NEMA MG1 part 31.4.4.2, 60 Hz Designs, Designed for longevity with a 4 year warranty on Super Premium efficient SP4 motors, Optimized airflow design providing higher horsepower in a smaller package, Cooler operation for longer lifespan
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$5,119.29 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Fans, Pumps, Blowers, Conveyors, Compressors, Industrial Machines, Other general purpose applications | ||||
| Enclosure: | TEFC | Frame Size: | 284TSC | Agency Approvals: | CSA EEV;NEMA_PREMIUM;UR;WEEE |
| Frame Material: | Iron | Poles: | 2 | Insulation Class: | F |
| Shaft Rotation: | Reversible | Base: | Rigid | Horsepower: | 25 Hp |
| Synchronous RPM: | 3600 | Speed RPM: | 3545 | Voltage: | 230/460V |
| Full Load Amps: | 56/28 | Service Factor: | 1.15 | Motor Weight: | 396.0 lbs |
| Duty Cycle: | Continuous | Overall Length: | 26.75 in | Frequency: | 60 Hz |
| Phase: | Three Phase | Efficiency: | 93 % | XP Temp Code: | T3A |
| Bearing DE: | 6312 | Bearing ODE: | 6311 | Ambient Temp: | 40 °C |
| Shaft Diameter: | 1.6250 in | Inverter Duty: | Inverter Duty | Shaft Grounding: | No Shaft Grounding |
| IP Rating: | IP55 | Standard: | NEMA | List: | 8341.00 |
