Baldor WCL1511T
* Actual Product May Differ From Image
WCL1511T
Part Number: WCL1511T
Model/Spec Number: 781568114827
Manufacturer: Baldor
HP: 10
RPM: 3450
Frame:Steel
Frame Size:215TCZ
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Oversize ball bearings for the pump industry, Locked DE bearing to allow mounting in any configuration, Dynamically balanced rotor to reduce noise and increase bearing life, Superior switch design provides optimized torque profiles
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$3,010.58 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Cement, Food, Beverage, Industrial pumps, Wastewater, Agricultural, Aggregate | ||||
| Enclosure: | ODP | Frame Size: | 215TCZ | Agency Approvals: | CSA;UR |
| Frame Material: | Steel | Poles: | 2 | Insulation Class: | F |
| Shaft Rotation: | Reversible | Base: | Rigid | Horsepower: | 10 Hp |
| Synchronous RPM: | 3600 | Speed RPM: | 3450 | Voltage: | 230V |
| Full Load Amps: | 46 | Service Factor: | 1.15 | Motor Weight: | 143.0 lbs |
| Duty Cycle: | Continuous | Overall Length: | 22.38 in | Frequency: | 60 Hz |
| Phase: | Single Phase | Efficiency: | 83 % | XP Temp Code: | Without |
| End Plate: | C-FACE | Bearing DE: | 6309 | Bearing ODE: | 6206 |
| Ambient Temp: | 40 °C | Shaft Diameter: | 0.8750 in | Inverter Duty: | Not Inverter |
| Shaft Grounding: | No Shaft Grounding | IP Rating: | NONE | Standard: | NEMA |
| List: | 4395.00 | ||||
