Baldor IDM3667T
* Actual Product May Differ From Image
IDM3667T
Part Number: IDM3667T
Model/Spec Number: 781568144480
Manufacturer: Baldor
HP: 1 1/2
RPM: 1170
Frame:Iron
Frame Size:182TC
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
TENV, TEFC, and TEBC 1000:1 Constant Torque, Provisions for encoder mounting , 3 Thermostats, Standard NEMA frame sizes
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$2,857.35 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Centrifugal Pumps, Fans, Extruders, Conveyors, Cranes, Hoists, Winders, Web processing, Process Control, Test Stands | ||||
| Enclosure: | TEBC | Frame Size: | 182TC | Agency Approvals: | CSA;UR |
| Frame Material: | Iron | Poles: | 6 | Insulation Class: | H |
| Shaft Rotation: | Reversible: Connected Standard | Base: | Rigid | Horsepower: | 1 1/2 Hp |
| Synchronous RPM: | 1200 | Speed RPM: | 1170 | Max Speed: | 2500 RPM |
| Base Speed: | 1200 RPM | Voltage: | 230/460V | Full Load Amps: | 5/2.5 |
| Service Factor: | 1.00 | Motor Weight: | 107.0 lbs | Duty Cycle: | Continuous |
| Overall Length: | 21.71 in | Frequency: | 60 Hz | Phase: | Three Phase |
| Efficiency: | 87.5 % | XP Temp Code: | Without | End Plate: | C-FACE |
| Bearing DE: | 6206 | Bearing ODE: | 6205 | Ambient Temp: | 40 °C |
| Shaft Diameter: | 1.1250 in | Inverter Duty: | Inverter Duty | Shaft Grounding: | No Shaft Grounding |
| IP Rating: | NONE | Standard: | NEMA | List: | 3729.00 |
