Baldor DRX21724T
* Actual Product May Differ From Image
DRX21724T
Part Number: DRX21724T
Model/Spec Number: 781568911242
Manufacturer: Baldor
HP: 7 1/2
RPM: 3510//2910
Frame:Iron
Frame Size:213T
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Robust steel and cast iron frames, 1.15 service factor, DE shaft slinger, UL breather drains, Threaded lead inlet
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$3,113.40 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Bulk fuel terminals, Division 1 hazardous areas, Transfer stations, Off-shore drilling | ||||
| Enclosure: | TEFC | Frame Size: | 213T | Agency Approvals: | CSA EEV;UL |
| Frame Material: | Iron | Poles: | 2 | Insulation Class: | F |
| Shaft Rotation: | Reversible | Base: | Rigid | Horsepower: | 7 1/2 Hp |
| Synchronous RPM: | 3600 | Speed RPM: | 3510//2910 | Max Speed: | 5400 RPM |
| Voltage: | 230/460V | Full Load Amps: | 18/9//15.2/7.6 | Service Factor: | 1.00 |
| Motor Weight: | 184.0 lbs | Duty Cycle: | Continuous | Overall Length: | 20.03 in |
| Frequency: | 50;60 Hz | Phase: | Three Phase | Efficiency: | 90.7 % |
| XP Temp Code: | T3C | End Plate: | STANDARD | Ambient Temp: | 40 °C |
| Shaft Diameter: | 1.3750 in | Inverter Duty: | Inverter Duty | Shaft Grounding: | No Shaft Grounding |
| IP Rating: | NONE | Standard: | NEMA | List: | 4621.00 |
