Baldor ECR584006-PPN
* Actual Product May Differ From Image
ECR584006-PPN
Part Number: ECR584006-PPN
Model/Spec Number: 781568908921
Manufacturer: Baldor
HP: 400
RPM: 1200//1200
Frame:Cast Iron
Frame Size:586/7TZ
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
High torque NEMA Design A, exceeds NEMA Design C torques, 1.25 Service Factor up to 100 HP, 1.15 Service Factor over 100 HP, Oversized ball bearings up to 50 HP, Ball and roller bearing designs 60 HP and above
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$37,877.24 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Above ground mining, Cement, Bulk material handling, Crushers, Belt conveyors, Aggregate | ||||
| Enclosure: | TEFC | Frame Size: | 586/7TZ | Agency Approvals: | - |
| Frame Material: | Cast Iron | Poles: | 6 | Insulation Class: | F |
| Horsepower: | 400 Hp | Synchronous RPM: | 1200 | Speed RPM: | 1200//1200 |
| Voltage: | 460V | Service Factor: | DETACH | Motor Weight: | 4806.0 lbs |
| Duty Cycle: | Continuous | Overall Length: | 65.72 in | Frequency: | 60 Hz |
| Phase: | Three Phase | Efficiency: | 95 % | XP Temp Code: | Without |
| Bearing DE: | 6322/C3 | Bearing ODE: | 6316/C3 | Ambient Temp: | 40 °C |
| IP Rating: | IP55 | Standard: | NEMA | List: | 61589.00 |
