Baldor SUM72506SM-4
* Actual Product May Differ From Image
SUM72506SM-4
Part Number: SUM72506SM-4
Model/Spec Number: 781568895795
Manufacturer: Baldor
HP: 25
RPM: 1160
Frame:Iron
Frame Size:250TY
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Continuous duty in water/sewage, 15 minute in air, 416 stainless steel shaft, Dual carbon ceramic mechanical seals, Two NC thermostats, Dual moisture sensing probes, 1.15 service factor, 5 year warranty
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$19,712.03 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Wet pit applications, Slurry pumps, Aerators, Mixers | ||||
| Enclosure: | TENV | Frame Size: | 250TY | Agency Approvals: | CCSA US |
| Frame Material: | Iron | Poles: | 6 | Insulation Class: | F |
| Shaft Rotation: | Reversible | Base: | Rigid | Horsepower: | 25 Hp |
| Synchronous RPM: | 1200 | Speed RPM: | 1160 | Voltage: | 230/460V |
| Full Load Amps: | 82/41 | Service Factor: | 1.15 | Motor Weight: | 496.0 lbs |
| Duty Cycle: | Continuous | Overall Length: | 37.93 in | Frequency: | 60 Hz |
| Phase: | Three Phase | Efficiency: | 86.7 % | XP Temp Code: | T3C |
| End Plate: | STANDARD | Bearing DE: | 60BC03JPP30A | Bearing ODE: | 40BC02JPG30A |
| Ambient Temp: | 0 °C | Shaft Diameter: | 1.4370 in | Inverter Duty: | Not Inverter |
| IP Rating: | NONE | Standard: | NEMA | List: | 27666.00 |
