Baldor SUM70754SM-4
* Actual Product May Differ From Image
SUM70754SM-4
Part Number: SUM70754SM-4
Model/Spec Number: 781568895764
Manufacturer: Baldor
HP: 7 1/2
RPM: 1745
Frame:Iron
Frame Size:180TY
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Continuous duty in water/sewage, 15 minute in air, 416 stainless steel shaft, Dual carbon ceramic mechanical seals, Two NC thermostats, Dual moisture sensing probes, 1.15 service factor, 5 year warranty
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$7,127.14 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Wet pit applications, Slurry pumps, Aerators, Mixers | ||||
| Enclosure: | TENV | Frame Size: | 180TY | Agency Approvals: | CCSA US |
| Frame Material: | Iron | Poles: | 4 | Insulation Class: | F |
| Shaft Rotation: | Reversible | Base: | Rigid | Horsepower: | 7 1/2 Hp |
| Synchronous RPM: | 1800 | Speed RPM: | 1745 | Voltage: | 230/460V |
| Full Load Amps: | 22.2/11.1 | Service Factor: | 1.15 | Motor Weight: | 248.9990 lbs |
| Duty Cycle: | Continuous | Overall Length: | 26.66 in | Frequency: | 60 Hz |
| Phase: | Three Phase | Efficiency: | 82.7 % | XP Temp Code: | T3C |
| End Plate: | STANDARD | Bearing DE: | 50BC02JPP30A | Bearing ODE: | 25BC02JPG30A |
| Ambient Temp: | 0 °C | Shaft Diameter: | 0.8750 in | Inverter Duty: | Not Inverter |
| IP Rating: | NONE | Standard: | NEMA | List: | 10003.00 |
