Baldor D2520R
* Actual Product May Differ From Image
D2520R
Part Number: D2520R
Model/Spec Number: 781568462560
Manufacturer: Baldor
HP: 20
Frame:Exposed Laminations
Frame Size:LC2512ATZ
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Laminated square frame for improved commutation, Class F insulation, Tachometer adaptable, Superior speed regulation, High limit thermostat
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$24,032.84 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Roofing machines, Paper, Textile equipment, Extruders, Machine tools, Metals | ||||
| Enclosure: | TEFC | Frame Size: | LC2512ATZ | Agency Approvals: | CCSA US |
| Frame Material: | Exposed Laminations | Insulation Class: | F | Base: | Rigid |
| Horsepower: | 20 Hp | Max Speed: | 2300 RPM | Base Speed: | 1750 RPM |
| Field Voltage: | 150V | Armature Current: | 71.0000 | Service Factor: | 1.00 |
| Motor Weight: | 640.0 lbs | Duty Cycle: | Continuous | Overall Length: | 38.94 in |
| XP Temp Code: | Without | Bearing DE: | 60BC03J30X | Bearing ODE: | 50BC02J30X |
| Ambient Temp: | 40 °C | Shaft Diameter: | 2.1240 in | Shaft Grounding: | No Shaft Grounding |
| IP Rating: | NONE | Standard: | NEMA | List: | 33206.00 |
