Baldor D1803R
* Actual Product May Differ From Image
D1803R
Part Number: D1803R
Model/Spec Number: 781568462355
Manufacturer: Baldor
HP: 3
Frame:Exposed Laminations
Frame Size:DC0189ATY
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Laminated square frame for improved commutation, Class F insulation, Tachometer adaptable, Superior speed regulation, High limit thermostat
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$11,462.03 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Roofing machines, Paper, Textile equipment, Extruders, Machine tools, Metals | ||||
| Enclosure: | DP | Frame Size: | DC0189ATY | Agency Approvals: | CCSA US |
| Frame Material: | Exposed Laminations | Insulation Class: | F | Base: | Rigid |
| Horsepower: | 3 Hp | Max Speed: | 4500 RPM | Base Speed: | 1750 RPM |
| Field Voltage: | 100/200V | Armature Current: | 14.8000 | Service Factor: | 1.00 |
| Motor Weight: | 165.0 lbs | Duty Cycle: | Continuous | Overall Length: | 21.19 in |
| XP Temp Code: | Without | Bearing DE: | 30BC02JPP30A | Bearing ODE: | 30BC02JPG30A |
| Ambient Temp: | 40 °C | Shaft Diameter: | 0.8750 in | Shaft Grounding: | No Shaft Grounding |
| IP Rating: | NONE | Standard: | NEMA | List: | 15837.00 |
