Baldor VP3316D
* Actual Product May Differ From Image
VP3316D
Part Number: VP3316D
Model/Spec Number: 781568154748
Manufacturer: Baldor
HP: .25/.33 kW/Hp
Frame:Steel
Frame Size:D71D
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Metric flange, Bolt on non-metric base, Class F insulation, Tachometer adaptable
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$837.47 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via UPS
Documents
Product Specifications
| Applications: | Fans, Conveyors, Blowers, Compressors, Pumps | ||||
| Enclosure: | TENV | Frame Size: | D71D | Agency Approvals: | CE;CSA;UR;WEEE |
| Frame Material: | Steel | Insulation Class: | F | Shaft Rotation: | Reversible |
| Base: | Rigid | Horsepower: | .25/.33 kW/Hp | Base Speed: | 1750 RPM |
| Armature Current: | 1.6000 | Service Factor: | 1.00 | Motor Weight: | 26.0 lbs |
| Duty Cycle: | Continuous | Overall Length: | 12.54 in | XP Temp Code: | Without |
| Bearing DE: | 6203 | Bearing ODE: | 6203 | Ambient Temp: | 40 °C |
| Shaft Diameter: | 0.5520 in | Shaft Grounding: | No Shaft Grounding | IP Rating: | NONE |
| Standard: | IEC | List: | 1243.00 | ||
