Baldor CJL1301A
* Actual Product May Differ From Image
CJL1301A
Part Number: CJL1301A
Model/Spec Number: 781568112854
Manufacturer: Baldor
HP: 1/3
RPM: 1725
Frame:Steel
Frame Size:56J
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
1.15 service factor, NEMA design B, UL file E481231, Exterior red paint RAL3002
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$560.33 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via UPS
Documents
Product Specifications
| Applications: | UL listed fire pump motors installed per NFPA-20 | ||||
| Enclosure: | ODP | Frame Size: | 56J | Agency Approvals: | CSA;UR |
| Frame Material: | Steel | Poles: | 4 | Insulation Class: | B |
| Shaft Rotation: | Fixed Opposite Standard | Base: | Rigid | Horsepower: | 1/3 Hp |
| Synchronous RPM: | 1800 | Speed RPM: | 1725 | Voltage: | 115/208-230V |
| Full Load Amps: | 6/3.2-3 | Service Factor: | 1.35 | Motor Weight: | 23.0 lbs |
| Duty Cycle: | Continuous | Overall Length: | 11.89 in | Frequency: | 60 Hz |
| Phase: | Single Phase | Efficiency: | 60 % | XP Temp Code: | Without |
| End Plate: | C-FACE | Bearing DE: | 6203 | Bearing ODE: | 6203 |
| Ambient Temp: | 40 °C | Shaft Diameter: | 0.6250 in | Inverter Duty: | Not Inverter |
| Shaft Grounding: | No Shaft Grounding | IP Rating: | NONE | Standard: | NEMA |
| List: | 818.00 | ||||
