Baldor VFSWDNM3554-4E
* Actual Product May Differ From Image
VFSWDNM3554-4E
Part Number: VFSWDNM3554-4E
Model/Spec Number: 781568594032
Manufacturer: Baldor
HP: 1 1/2
RPM: 1765
Frame:Stainless Steel
Frame Size:56C
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
300 series stainless steel, Individually welded feet for ease of cleaning, Smooth heads on external drains & hardware, Welded and polished conduit box, Laser marked nameplate, Internal & External shaft sealing, 3 Year Warranty
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$1,946.78 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via UPS
Documents
Product Specifications
| Applications: | Caustic environment, Food Processing, High pressure washdown, Outdoors, Pumps, Wastewater, Sanitary washdown | ||||
| Enclosure: | TENV | Frame Size: | 56C | Agency Approvals: | CURUSEEV;NEMA_PREMIUM;WEEE |
| Frame Material: | Stainless Steel | Poles: | 4 | Insulation Class: | H |
| Shaft Rotation: | Reversible | Base: | No Mounting | Horsepower: | 1 1/2 Hp |
| Synchronous RPM: | 1800 | Speed RPM: | 1765 | Voltage: | 460V |
| Full Load Amps: | 1.95 | Service Factor: | 1.15 | Motor Weight: | 59.0 lbs |
| Duty Cycle: | Continuous | Overall Length: | 16.21 in | Frequency: | 60 Hz |
| Phase: | Three Phase | Efficiency: | 86.5 % | XP Temp Code: | Without |
| Bearing DE: | 6205 | Bearing ODE: | 6205 | Ambient Temp: | 40 °C |
| Shaft Diameter: | 0.6250 in | Shaft Grounding: | No Shaft Grounding | IP Rating: | NONE |
| Standard: | NEMA | List: | 2922.00 | ||
