Baldor VFSWDM3714T-5E
* Actual Product May Differ From Image
VFSWDM3714T-5E
Part Number: VFSWDM3714T-5E
Model/Spec Number: 781568940105
Manufacturer: Baldor
HP: 10
RPM: 1770
Frame:Stainless Steel
Frame Size:215TC
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
300 series stainless steel, Individually welded feet for ease of cleaning, Smooth heads on external drains & hardware, Welded and polished conduit box, Laser marked nameplate, Internal & External shaft sealing, 3 Year Warranty
Want yours repaired?
Call us for repair and exchange pricing
Contact supplier for technical support: 586-469-0710
Returns: See policies
Payment methods:
$4,591.13 /each
Base price only. Shipping, sales tax (if applicable) and a 3% credit card fee may apply.
Please call or request a quote below for availability
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
586.469.0710
Typically Ships: 1-2 Days Warranty: 2 Year from Date of Shipment
Ships via Freight
Documents
Product Specifications
| Applications: | Caustic environment, Food Processing, High pressure washdown, Outdoors, Pumps, Wastewater, Sanitary washdown | ||||
| Enclosure: | TEFC | Frame Size: | 215TC | Agency Approvals: | CSA;UR |
| Frame Material: | Stainless Steel | Poles: | 4 | Insulation Class: | H |
| Shaft Rotation: | Reversible | Base: | No Mounting | Horsepower: | 10 Hp |
| Synchronous RPM: | 1800 | Speed RPM: | 1770 | Max Speed: | 4500 RPM |
| Voltage: | 575V | Full Load Amps: | 10.1 | Service Factor: | 1.00 |
| Motor Weight: | 187.0 lbs | Duty Cycle: | Continuous | Overall Length: | 22.12 in |
| Frequency: | 60 Hz | Phase: | Three Phase | Efficiency: | 92.4 % |
| XP Temp Code: | Without | End Plate: | C-FACE | Bearing DE: | 6307 |
| Bearing ODE: | 6307 | Ambient Temp: | 40 °C | Shaft Diameter: | 1.3750 in |
| Inverter Duty: | Inverter Duty | Shaft Grounding: | No Shaft Grounding | IP Rating: | NONE |
| Standard: | NEMA | List: | 6891.00 | ||
